EC-102

The EC-102 is a very efficient Robotic Palletiser utilizing only 2.5 kVA. The EC-102 offers a higher palletising capacity than the previous EC-101 making this a very popular robot among moderate production rates. With two EC-102 models Fuji offers a solution for High Speed (HS) and/or Heavy Weight (HD) applications.

Key Benefits

  • Capacity (cycles/hour) 1300
  • Payload (inc. hand) 70 Kg
  • Main body weight 700 Kg
  • Power (220V, 3PH, 50/60 Hz) 2.3 KVA

Operational Space:

  • Z axis (vertical) 2300mm
  • R axis (reach) 1500mm
  • θ axis (turn) 330°
  • α axis (wrist) 330°

Optional Extras

  • Pallet Magazines- To supply empty pallets one at a time to pallet line.
    Can also be used to stack empty pallets in a de-palletizing system.
    Maximum stack – 900kg.
  • Slipsheet and Tray Applicators- Automatically place plastic slip sheets from a roll, cardboard slip sheets from a stack and place then erect trays from a stack.
  • Pick-up conveyors- Powered rollers allowing the robot hand to gently
    pick up product.
  • Harsh Environment Jackets- To protect the robot from hostile environments.
  • Pallet Conveyors- Bespoke manufacture to suit customers plant layout and special requirements

Data Sheet

EC-102 Data Sheet Download
